MAK Spares
Manufacture cylinder liner ,piston ring,liner sleeve as one of the Indian railway approved vendor sources.
ITEM DESCRIPTION
C&D NO.
DRG. NO.
Cylinder Liner
M 101/001
1.20.6.16.11.01.02
Piston Ring Sets
-
0.00.6.35.41.02.16
Piston Ring (Spherically Lapped)
M 119/013
0.00.6.35.41.02.16
Piston Ring (With Mola Coating)
M 119/014
0.00.6.35.41.02.07
Oil Wiper Ring (Piston)
M 119/015
0.00.6.35.41.02.03
Valve Seat Ring
M 202/010
1.20.6.21.41.03.01
Valve Intel & Exhaust
M 209/001
1.20.6.22.10.01.08
Valve Guide Bush
M 211/005
1.20.7.21.41.02.06
Cylinder Head
M 202/009
1.20.7.21.51.00.02
Valve Spring
M 209/008
1.20.6.22.10.02.05
Spring Base
M 209/009
1.20.7.22.10.03.03
Valve Tapper Piece
M 209/010
0.00.6.13.15.00.01
Rectangular Ring
M 211/007
4/DE/08/004
Security Ring
M 211/006
1.20.7.22.15.01.01
Cam shaft
M 301/001
1.23.7.31.03.00.02
Exhaust Cam
M 301/006
1.20.7.32.22.01.03
Fuel Cam
M 302/001
1.20.7.32.32.01.01
Adopter Sleeve
M 302/002
1.20.7.32.32.02.01
Groove Nut
M 302/003
1.20.7.32.32.02.01
Grub Screw AM 8X8
Din=913-8.8
-
Clamping Sleeve 8X10
Din=1481
-
Inlet Cam
M 301/005
1.20.7.31.12.01.03
Hex Screw AM 10 X 20
M 301/010
4DE/18/079
Set coller
M 301/004
1.20.7.31.03.04.01
Hex Nut
M 301/007
1.20.7.31.03.07.01
Locking Sheet
M 301/008
1.20.7.31.03.10.01
Locking Part
M 302/004
1.20.7.32.32.04.01
Spring Washer
M 201/023
1.20.7.21.04.01.01
Intermediate Piece
M 309/002
1.20.7.35.65.03.03
Guide Body(Tappet)
M 305/004
1.20.7.35.66.00.03
Adjusting Screw
M 206/014
1.20.6.35.20.04.02
Hexagon Nut
M 201/068
1.00.7.88.50.58.07
Inlet Valve Rocker Arm (Push Rod Side)
M 201/053
1.20.7.35.10.03.04
Bush
M 204/005
1.20.7.35.30.02.02
Roller with bearing & Pin
M 306/004
1.20.6.35.67.00.03
Inlet Rocker Arm.
M 201/052
1.20.7.35.20.02.02
Exhaust Valve Rocker Arm Complete
M 206/010
1.20.7.35.20.00.04
Bush
M 204/005
1.20.7.35.30.02.02
Inlet Valve Rocker Arm
M 205/004
1.20.7.35.11.00.02
Diring Metallic Gasket
M 101/006
1.20.6.16.11.02.02
Push Rod
M 307/000
1.20.7.35.70.01.01
Ball Socket
M 307/002
1.20.7.35.70.02.01
Ball Inset
M 307/003
1.20.7.35.70.03.01
Protection Pipe
M 304/006
1.20.7.35.80.04.01
Guide Pin
-
2DE/02-009 Reg At.
Ball Socket
M 305/006
1.20.7.35.66.03.04
Guide Body
M 305/005
1.20.7.35.65.02.03
Roller with Bearing & Pin
M 306/004
1.20.6.35.67.00.03
Bush for Roller Guide
M 102/010
1.20.7.11.21.10.02
Flange
M 210007
1.20.7.22.52.01.03
Indicator Valve
M 210009
0.00.6.41.20.00.23
